DCS520 54V Plunge Saw

The XR FLEXVOLT DCS520 is the first Plunge Saw to feature a Brushless 54V Motor, making it one of the most powerful cordless plunge saws available. The DCS520 is extremely accurate making it ideal for general carpentry and woodworking, with particular suitability towards cabinet making, kitchen fitting or hard wood floor installation. The DCS520 plunge saw is quick and easy to adjust and features accurate bevel to 47 degrees, twin edge track system, a comfortable ergonomic rubber grip for superior control and the parallel link plunge mechanism. The DCS520 plunge saw also benefits from Airlock dust extraction port and is compatible with a range of DEWALT dust extractors.




55 mm cut depth


Number of cuts per single charge: 76m in 18mm plywood


Brushless 54V Motor


Accurate Bevel System


Lightweight and portable

Voltage 54 V
Blade Speed 165mm
Blade Size 165 mm
Bore 20 mm
Max Depth of Cut (at 90 degrees on track): 55 mm
Mitre 15 degrees
Bevel Capacity 0 - 47 °

Shoe Chip Collection Bag
Aluminium Airlock Compatible for effective dust collection
Weight 5.5 Kg
Depth 235mm
Length 330mm
Height 270mm
Logo extreme runtime


Accessories-PLUNGESAW Maximise productivity by using XR FLEXVOLT optimised table saw blades - cutting up to 63% more metres per charge than a DEWALT construction blade.

image saw blade teeth-1

The optimised tooth form combining two alternate top bevel teeth followed by a raker tooth allows for the efficient cutting and cleaning of the kerf. This minimises the battery power required to make the cut line and prolong's battery life.


By reducing the width of the carbide teeth, this reduces the resistance in the timber. Less power is required to drive the teeth through the wood, further reducing battery power usage and further prolonging battery life..
