DCF520N-XJ

18V XR® Brushless 1/4-in & 3/8-in Sealed Head Ratchet (Tool Only)

DEWALT ratchet tool, photography category. SKUs: DCF520N-XJ, DCF520N. Yellow and black cordless model.

Reviews

Product details

Complete challenging applications with the versatile 18V XR® Brushless Cordless 1/4-in & 3/8-in Sealed Head Ratchet. Our highest speed 18V XR® ratchet delivers a no-load speed up to 450 RPM and up to 75Nm of max torque. Take advantage of the interchangeable anvil design to quickly swap between 3/8-in square drive, 1/4-in square drive, and 1/4-in low-profile hex anvils for versatility in a wide range of applications. Featuring a sealed-head, a trigger lock, and a built-in LED, this next-generation XR® tool is engineered to take on tough fastening jobs.

  • 18V XR® Brushless Sealed Head Ratchet 1/4-in 3/8-in And 1/4-in Quick-Change™ Hex
  • Brushless motor: Delivers 67 Nm of max torque and a no-load speed of 0-450 rpm
  • Interchangeable anvil design: Provides the ability to quickly swap between 3/8-in, 1/4-in and 1/4-in Quick-Change™ hex drive
  • Forward, reverse and variable speed: For total control
  • Bright white LED: For excellent workpiece lighting
  • Trigger lock-off technology: For increased worksite safety
  • Oil-resistant glass-filled nylon tool housing: Resists effects of harsh automotive oils and solvents

Product Type
Cordless Ratchet
Voltage
18V
Cordless or Corded
Cordless
Power Source
Battery
Motor Type
Brushless

  • (1) 18V Ratchet
  • (1) 3/8-in Anvil
  • (1) 1/4-in Anvil
  • (1) 1/4-in Quick-Change™ Hex

  • 1 Year Limited Warranty, 3 Year Limited Warranty When Registered
